EDS-408A-MM-ST V1.2.1 Сетевой коммутатор МОХА

Vendor Name: MOXA Construction Construction Chassis: Metal Chassis Mounting Configuration: Wall, DIN-Rail mount Protection Level of Chassis: IP30 Network Adapter Total Ethernet: 8 10/100 Mbit/s: 8 Type 10/100 Mbit/s: 3xSC, 5xRJ-45, Single-mode Type Ethernet: 10BASE-T, 100BASE-F, 100BASE-T Network Technology Managed: Yes, Layer 2 Protocol: IGMPv1/v2, DHCP Server/Client, DHCP Option 66/67/82, EtherNet/IP, NTP Server/Client, SNTP, SMTP, SNMP Inform, SNMPv1/v2c/v3, BootP, GMRP, GVRP, HTTP, LLDP, RARP, RMON, Syslog, Telnet, TFTP, VLAN, STP/RSTP, Modbus TCP, Turbo Ring, Turbo Chain IEEE Standard: IEEE 802.1D-2004 for Spanning Tree Protocol, IEEE 802.1P for Class of Service, IEEE 802.1Q for VLAN Tagging, IEEE 802.1W for Rapid Spanning Tree Protocol, IEEE 802.3 for 10BaseT, IEEE 802.3u for 100BaseT(X) and 100BaseFX, IEEE 802.3x for Flow Control IP Layer: IPv4, IPv6 Switch Properties MAC Table Size: 8000 Packet Buffer Size: 1 MBit Technologies and Functions Supported functions: Port Mirror, Rate Limit, Loop Protection, Broadcast Storm Protection, Port-Based VLAN, Automatic power failure notification, Automatic port failure notification, Flow Control, Back pressure flow control, Line-Swap Fast Recovery, Supports network management system Industrial Protocols EtherNet/IP: Yes Modbus TCP: Yes Digital Output Total channels of digital output: 1 Type: Signal Relay Contact rating of relay (Form A): 1A@24V DC Cooling Type: Fanless LED / Controls LED: FAULT LED, MSTR/HEAD LED, CPLR/TAIL LED, 10/100M LED, PWR1, PWR2 Setup of Operation Mode: Telnet, Console Port, By Switches, Web-interface, Command Line Interface (CLI), Through MXconfig Utility Connectors / Cables Connectors: Console Port RS-232 (RJ-45) System Power Input Input Voltage DC: 19 ... 60 V (±24/±48 VDC) Power Consumption: 6.7 W Current: 0.28 A (24 V) Power Supply Reserve input Voltage DC: 19 ... 60 V (±24/±48 VDC) Power Consumption Reserve: 6.7 W Current Reserve: 0.28 A (24 V) Power Input Protection: Fuze, Reverse Polarity Operating Conditions Temperature: -10 ... 60 °C Humidity: 5 ... 95 % (non-condensing) MTBF: 363000 h Storage Conditions Temperature Range: -40 ... 85 °C Dimensions and weight Width: 53.6 mm Height: 135 mm Depth: 105 mm Standards and Certifications Vibration And Shock: IEC 60068-2-6, IEC 60068-2-27 Freefall: IEC 60068-2-32 Safety: UL 508 EMS: IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, EN 55032 EMI: FCC Part 15 Subpart B Class A, CISPR 32
