KEW 2056R - Hozirgi o'lchov pense

KEW 2056R qisqich o'lchagichining texnik xususiyatlari: Umumiy tavsif AC tok chegaralari 0 - 600/1000 A aniqlik +/- 2,0% rdg +/- 5 rdg (50/60 Hz); +/- 3,5% rdg +/- 5 rdg (40 Hz - 400 Hz) AC kuchlanish chegaralari 6/60/600 V xato +/- 1,5% rdg +/- 4 rdg (50/60 Hz); +/- 3,5% rdg +/- 5 rdg (40Hz - 400Hz) DC oqim chegaralari 0 - 600/1000 A aniqlik +/- 1,5% rdg +/- 5 rdg DC kuchlanish 600 mV / 6/60/600 V aniqligini +/- 1% rdg +/- 3 rdg chegaralarini cheklaydi Qarshilik chegaralari 60 Ohm / 6 kOhm / 60 kOhm / 600 kOhm / 6 MOhm / 60 MOhm xato +/- 1% rdg +/- 5 rdg (600 Ohm - 6 MOhm); +/- 5% rdg +/- 8 rdg (60 MΩ) Chastota / yuk 10Hz / 100Hz / 1kHz / 10kHz / 0.1 ~ 99.9% Davomiylik davri signallari 100 ohmda eshitiladi Maksimal atrof diametri 40 mm Imkoniyat 400 nF / 4 mF / 40 mF Xavfsizlik standarti IEC 61010-1 CAT IV 600 V, IEC 61010-031, IEC 61010-2-032, IEC 61326 5 soniya davomida 6880 VAC kuchlanish chegarasi R03 (1,5 V) (AAA) x 2 quvvat manbai Olchamlari / Og'irligi 254 x 82 x 36 mm / 0.31 kg
