MSI PRO B760-P II DDR5 LGA1700 anakart

Tavsif

• Socket: LGA 1700

• Chipset nomi: Intel B760

• Form-faktor: Standard-ATX

• Protsessor ishlab chiqaruvchisi: Intel

• Xotira turi: DDR5 DIMM

• Xotira uyalar soni: 4

• M.2 uyalar soni: 2

• PCI-E x16 uyalar soni: 1

• PCI-E x1 uyalar soni: 0

• Simli bo‘lmagan interfeyslar: Wi-Fi, Bluetooth

• Maksimal xotira chastotasi: 5600 MHz

• SLI/CrossFire qo‘llab-quvvatlanadi: yo‘q

Texnik xususiyatlar

Tur: Matritsa platalar (Motherboard)
Model: MSI PRO B760-P II
Seriya: MSI PRO
Chiqarilgan yili: 2024

Form-faktor va o‘lchamlar

• Form-faktor: Standard-ATX

• Balandligi: 305 mm

• Kengligi: 244 mm

Protsessor va chipset

• Socket: LGA 1700

• Chipset: Intel B760

• Intel protsessorlari bilan mos keladigan yadrolar: Alder Lake, Raptor Lake Refresh, Raptor Lake

Xotira

• Qo‘llab-quvvatlanadigan xotira turi: DDR5

• Form-faktor: DIMM

• Uyalar soni: 4

• Kanal soni: 2

• Maksimal xotira hajmi: 256 GB

• Maksimal chastota (JEDEC/overclocksiz): 5600 MHz

• Chastota overclock bilan: 5800, 6000, 6200, 6400, 6600, 6800 MHz

Kengaytirish uyalar

• PCI Express versiyasi: 4.0

• PCIe x16 uyalar: 1 x PCIe 4.0 (x16), 1 x PCIe 4.0 (x4), 3 x PCIe 3.0 (x1)

• SLI/CrossFire: yo‘q

Saqlash qurilmalarini boshqarish

• NVMe qo‘llab-quvvatlash: ha

• M.2 uyalar: 2

• SATA portlar: 4

• SATA RAID rejimi: 0, 1, 5, 10

Orqa panel portlari

• USB Type-A: 2 x USB 2.0, 2 x USB 3.2 Gen 1

• USB Type-C: 1 x USB 3.2 Gen 2

• Video chiqishlar: 1 x HDMI, 1 x DisplayPort

• RJ-45 portlar: 1

• Analog audio: 5

• Optik S/PDIF: TOSLINK

Ichki portlar

• USB Type-A: 2 x USB 3.2 Gen 1 (19-pin), 2 x USB 2.0 (9-pin)

• USB Type-C: 1 x USB 3.2 Gen 1

• CPU fan: 1 x 4-pin

• SVO pompasi: 1 x 4-pin

• Korpus fanlari: 5 x 4-pin

• ARGB: 2 x 3-pin

• RGB: 2 x 4-pin

• RS-232 (COM): ha

Audio

• 7.1 kanal

• Chip: Realtek ALC897

Tarmoq

• Tezlik: 2.5 Gbit/s

• Chip: Realtek RTL8125BG

Quvvat va sovutish

• Asosiy quvvat: 24-pin

• CPU quvvati: 8-pin + 4-pin

• Quvvat fazalari: 12+1+1

• Passiv sovutish: VRM, chipset, 1 x M.2

• Faol sovutish: yo‘q

Qo‘shimcha xususiyatlar

• Intel XMP qo‘llab-quvvatlash

• TPM 2.0 qo‘llab-quvvatlash

Komplektatsiya: Orqa panel, M.2 montaj elementi, SATA kabeli
Kafolat: 1 yil
