Viktor 88B - raqamli multimetr

Viktor 88B raqamli multimetrining texnik xususiyatlari:
Parametr O'lchov diapazonlari Aniqlik
Ruxsat etilgan kuchlanish 200mV ±(0,5% + 5)
2V/20V/200V ±(0,5%+3)
1000V ±(1,0% + 10)
O'zgaruvchan kuchlanish 2V/20V/200V ±(0,8%+5)
750V ±(1,2% + 10)
Doimiy oqim 200uA/2mA/20mA/200mA ±(1,2%+8)
20A ±(2,0% + 5)
AC oqimi 20mA ±(1% + 5)
200 mA ±(2% + 5)
20A ±(3,0% + 10)
Qarshilik 200 ohm ±(0,8% + 5)
2kŌ/20kũ/200kũ/2MŌ ±(0,8% + 3)
20 MŌ ±(1,0% + 25)
200 MŌ ±(5,0% + 30)
Imkoniyatlar 20nF/200nF/2uF ±(3,5% + 20)
20uF/200uF/2000uF ±(5,0% + 10)
Chastota 10Hz/100Hz/1KHz/10KHz/100KHz/1MHz ±(1,0%+10)
Harorat -20°C~400°C/-4°F~752°F ±(1,0% + 5)
400°C~1000°C/752°F~1832°F ±(1,5% + 15)
Diyot testi Diyot bo'ylab to'g'ridan-to'g'ri kuchlanish pasayishining taxminiy qiymatini ko'rsatadi
"Uzluksizlik" O'chirish qarshiligi (50±20) Ohm dan kam bo'lsa, ovoz signali yoqiladi.
hFE Tekshirilayotgan tranzistorning taxminiy hFE qiymatini (0-1000) ko'rsatadi (har qanday turdagi)
Kuchlanish ko'rsatkichi TEST O'qish 000 yoki 1
